Dab NOVA 180 M-NA

Dab NOVA 180 M-NA
From € 177,00 Now € 159,30 ex vat
Your discount: 10%
€ 192,75 inc vat
Out of stock, Exp. delivery in 3 days
Product ID 01400041
Brand Dab
Voltage 1x230V
Height in mm 25
Frequency 50 Hz
Maximum head in mwc 4.45
Maximum flow in L/min 83.3
Capacity in m³/h at 1 mwc 5
Capacity in m3/h at 3 mwc 3
Capacity in m3/h at 4 bar 2
Article number factory 60195632H
Max particle passage size in mm 5
Type / Model Nova
Connection in inch
Cable length in meters 10
Power in Kw 0,20
Geleverd met vlotter Nee
Breedte in mm 15
Lengte in mm 15
The Dab Feka is suitable for the draining of clean water for domestic use.
These pumps are perfect to pump (drain) basements and sewage water from septic tanks. The pump works easily and is known for its quality.

Characteristics:
    Maximum dry-running time: 1 minute
    Installation: fixed or portable in vertical position
    Protection class: IP 68


Construction:
Pump body, impeller, cap and suction grid in technopolymer.
Motor, rotor shaft and screws in stainless steel.
Triple O-ring seal interposed with an oil precombustion chamber.
Continuous duty submersible asynchronous motor.
Stator fitted in an airtight stainless steel casing.
Rotor mounted on overdimensioned, greased-for-life ball bearings.
Built-in thermal and current overload protection and a capacitor permanently on in the single-phase version.

Note: A models have an automatic float switch, which NA models do not have.
Keywords: Dompelpomp, vlakzuiger
Stock 0 pieces
