Dab NOVA 180 M-NA
| Art ID | 01400041 |
|---|---|
| Description | Dab NOVA 180 M-NA |
| In stock | |
| Delivery time | 3 business days |
| Price excluding taxes | €163,80 |
| Price incl. VAT | €198,20-10% |
€198,20
(Incl. btw)
Amount
Out of stock, please contact us. Delivery time 5 days.
Characteristics
| Article number | 01400041 |
|---|---|
| Merk | Dab |
| Voltage | 1x230V |
| Hoogte in mm | 25 |
| Frequentie | 50 Hz |
| Max. opvoerhoogte in MWK | 4.45 |
| Max. debiet in L/min | 83.3 |
| Max. debiet in m3/uur | 5 |
| Capaciteit in m3/h bij 1 MWK | 5 |
| Capaciteit in m3/h bij 3 MWK | 3 |
| Capaciteit in m3/h bij 4 MWK | 2 |
| Artikelnummer fabrikant | 60195632H |
| Doorlaat in mm | 5,0 |
| Type / Model | Nova |
| Aansluiting in inch | 1¼ |
| Kabellengte in meters | 10 |
| Vermogen in kilowatt | 0,20 |
| Geleverd met vlotter | Nee |
| Breedte in mm | 15 |
| Lengte in mm | 15 |
Description
The Dab Feka is suitable for the draining of clean water for domestic use.
These pumps are perfect to pump (drain) basements and sewage water from septic tanks. The pump works easily and is known for its quality.
Characteristics:
- Maximum dry-running time: 1 minute
Installation: fixed or portable in vertical position
Protection class: IP 68
Construction:
Pump body, impeller, cap and suction grid in technopolymer.
Motor, rotor shaft and screws in stainless steel.
Triple O-ring seal interposed with an oil precombustion chamber.
Continuous duty submersible asynchronous motor.
Stator fitted in an airtight stainless steel casing.
Rotor mounted on overdimensioned, greased-for-life ball bearings.
Built-in thermal and current overload protection and a capacitor permanently on in the single-phase version.
Note: A models have an automatic float switch, which NA models do not have.
PDF download click here for technical specifications.
